i LoVE bLuE

Wireless

0 R name=”AP” mtu=1500 mac-address=xx:xx:xx:xx:xx:xx arp=enabled
interface-type=Atheros AR5413 mode=ap-bridge ssid=”aska”
frequency=2422 band=2.4ghz-b/g scan-list=default antenna-mode=ant-a
wds-mode=disabled wds-default-bridge=none wds-ignore-ssid=no
default-authentication=yes default-forwarding=yes default-ap-tx-limit=0
default-client-tx-limit=0 hide-ssid=no security-profile=mac
compression=no

1 R name=”P2P” mtu=1500 mac-address=xx:xx:xx:xx:xx:xx arp=enabled
interface-type=Atheros AR5413 mode=station ssid=”luna”
frequency=2312 band=2.4ghz-b scan-list=2312-2399 antenna-mode=ant-a
wds-mode=disabled wds-default-bridge=none wds-ignore-ssid=no
default-authentication=yes default-forwarding=yes default-ap-tx-limit=0
default-client-tx-limit=0 hide-ssid=no security-profile=default
compression=no

Bridge

0 R name=”AP-Bridge” mtu=1500 arp=enabled mac-address=xx:xx:xx:xx:xx:xx
protocol-mode=none priority=0×8000 auto-mac=yes
admin-mac=00:00:00:00:00:00 max-message-age=20s forward-delay=15s
transmit-hold-count=6 ageing-time=5m

Port

# INTERFACE BRIDGE PRIORITY PATH-COST HORIZON
0 AP AP-Bridge 0×80 10 none
1 POE AP-Bridge 0×80 10 none

================= STATUS ====================================

P2P :
status: connected-to-ess
band: 2.4ghz-b
frequency: 2312MHz
tx-rate: “11Mbps-SP”
rx-rate: “11Mbps-SP”
ssid: “luna”
bssid: xx:xx:xx:xx:xx:xx
radio-name: “SYIFA”
signal-strength: -60dBm
tx-signal-strength: -45dBm
noise-floor: -102dBm
signal-to-noise: 42dB
tx-ccq: 100%
rx-ccq: 20%
p-throughput: 7823
overall-tx-ccq: 100%
authenticated-clients: 1
current-ack-timeout: 43
wds-link: no
nstreme: no
framing-mode: none
routeros-version: “3.2″
last-ip: 74.125.103.39
802.1x-port-enabled: yes
compression: no
current-tx-powers: 1Mbps:17(17),2Mbps:17(17),5.5Mbps:17(17),11Mbps:17(17)
notify-external-fdb: no

AP :

status: running-ap
band: 2.4ghz-g
frequency: 2422MHz
noise-floor: -103dBm
overall-tx-ccq: 67%
registered-clients: 21
authenticated-clients: 21
current-ack-timeout: 321
nstreme: no
current-tx-powers: 1Mbps:14(14),2Mbps:14(14),5.5Mbps:14(14),11Mbps:14(14),6Mbps:14(14),9Mbps:14(14),12Mbps:14(14),18Mbps:14(14),24Mbps:14(14),36Mbps:14(14),
48Mbps:14(14),54Mbps:14(14)
notify-external-fdb: yes

result :

hiks… AP nya tinggi timeoutnya, CCQ nya kurang bagus ma client, kondisi client dengan bermacam merek radio masih lom optimal, ada yang makai NS, JAHT, SENAO, EOC…

Walau sebenarnya ini sepele, terkadang ada beberapa kondisi kita mesti nge set jam di router kita ^^

root@www:~# date 122318112006
Sat Dec 23 18:11:00 WIT 2006

hahahahaha

Nah, ngelanjutin tujuan ku bikin mikrotik, sekarang aku ngeset PPTP-Client nya :
[ip nya sample lo, untuk menjaga pihak~ tertentu ]

[admin@MikroTik] > interface pptp-client add name=pesawat connect-to=202.202.202.202 user=gue add-default-route=yes password=gua
Continue reading PPTP-Client…
